H2430NC - Clausing Kalamazoo Double Column Fully Automatic Horizontal Bandsaw 24.4” x 30” Max Rectangular Capacity
Have one to sell?
ConditionNew
New
Clausing Kalamazoo Double Column Fully Automatic Horizontal Bandsaw 24.4” x 30” Max Rectangular Capacity, 24.4” Round Capacity, 66 to 328 SFPM Blade Speed, 10 Hp drive motor, 230 volts 3 Phase
Features and Benefits:
This model is designed for rugged production use, and it offers high production output and heavy-duty performance in fully automatic operation. Voltage specific model, at either 230 or 460, may require a transformer or special order.A powerful drive motor provides the power, and the Smart NC-20 technology programmable different jobs.Three phase refers to three individual lines that connect to and run voltage through the motor. Each line alternates in a sequence as it reaches its voltage peak. This provides for a more stable flow of voltage and more horsepower to the machine.
Drive Type Heavy duty inverter blade drive system
Maximum Capacity Round (inch) 24.4
Maximum Capacity Rectangle (inch) 24.4 x 30
Voltage 230
Phase 3
Coolant System Yes
Angular Cuts at 45 Degrees (inch) N/A
Blade Size 2” x .06” x 283”
Blade Speeds (SFPM) 66-328
Blade Guide Type Carbide
Motor Horsepower 10
Heavy duty inverter blade drive system
NC Controlled multiple indexing for long cutting lengths up to 650”
Oversized precision ground, large dual columns
Precision feed pressure & feed rate valve system
Automatic hydraulic blade tensioning device
Smart NC-20 Control
Cross link connecting two columns for enhanced structural strength
Full stroke ductile cast iron split vise
Proximity switch for sensing blade slippage or breakage
Discharge table with built-in coolant return
Synchronized power driven blade brush
Cam lock carbide blade guides with bearing guides
“Last cut” or “keep on” selector
2 Year limited warranty
