ConditionNew
Have one to sell?

Overview

Type:
CNC Lathes
Manufacturer:
MIGHTY VIPER
Model:
VT-40A
Condition:
Build To Order
Status:
For Sale

Description

38~70A VT-Series accommodates long and heavy workpieces; provides deep hole boring capacity with a large diameter.

Swing39.37"1,000 mm
Chuck Size18"457.2 mm
Bar Capacity5.12"130.05 mm
Power60 hp44.7 kW
Max RPM2,100 RPM2,100 RPM
Turning Dia32.28"819.91 mm

Swing Over Bed 39 (1000)
Turning Diameter Max. 35 (880)
Turning Length Max. 38~156 (960~3960)
X-Travel 17+1.18 (430+30) 21+1.18 (540+30)
Z-Travel 39~157 (1000~4000)
Thru Bar Capacity 4.5 / 6.3 (115/160)
Boring Bar Dia. Max. 2.5 / 4.0 (60/100)
Spindle Thru Hole 5.2~12.0 (131~308)
Spindle Nose A2-11~A2-20
Spindle Speed Range 300 ~2500
Spindle Motor** 50 / 60*
Tool Number 12
Units = inch(mm) *Optional accessory **30 min. rating
